LA9650 55FT UNIT

Product Description

High-Capacity, Precision Liquid Fertilizer Applicators Built for Maximum Field Efficiency

When every pass matters, the Ag Spray Equipment LA9000 Series Liquid Applicators deliver the capacity, consistency, and durability needed to keep your operation running at peak performance. Designed for large-acreage operations, these applicators combine high-volume liquid handling with precision placement—helping you maximize yields while minimizing waste.

Available in working widths from 27 feet to 55 feet and tank capacities of 1,650 to 1,950 gallons, the LA9000 Series is built to handle demanding application environments with ease.

Key Features of the LA9000 Series

• Adjustable Constant Wing Down Pressure – Ensures consistent ground contact for even application across varying terrain
• Deep Sloping Sump Design – Promotes complete tank drainage and minimizes product waste
• Tank Baffle System – Reduces liquid sloshing for improved stability in transport
• Auto Gull Wing Design – Simplifies lifting and turning while maintaining structural integrity
• Front-Mount Toolbar – Enhances trailing performance and application accuracy
• Gauge Wheels – Maintain consistent depth and placement across the toolbar
• Built-In Toolbox – Convenient onboard storage for tools and maintenance items

Available Models & Configurations

The ASLA9000 Series includes both LA9650 (1,650 gallon) and LA9950 (1,950 gallon) units, available in multiple widths:

LA9000 Series Bar Sizes

• 27’ Liquid Applicator
• 30’ Liquid Applicator
• 35’ Liquid Applicator
• 40’ Liquid Applicator
• 55’ Liquid Applicator

All models feature a 6x4 double bar configuration for strength, stability, and consistent application performance.

Axle & Tire Options

Customize your applicator to match your field conditions and row spacing:

• 20K Axle Options (Single Tire Configurations)
  • 380/90R54 or 480/80R42 tire options
  • Adjustable widths from 60” to 152”
• Dual Wheel Configurations (Required for 1,950 Gallon Units)
  • IF320/90R54 or IF380/90R54 tire options
  • Width ranges from 60” to 152” depending on setup

Built for stability, load capacity, and reduced compaction in demanding field conditions.

Pump System Options

Designed for reliable flow and efficient transfer:

• Wheel-to-Wheel Drive Piston Pump Systems
  • 7055SS or 9055SS piston pump options
• Hydraulic Driven Centrifugal Pump (93100 PWM)
• Standard Features Include:
  • 3” Quick Fill System
  • 1” Feed Lines
  • Filter Assembly
  • 4” Pressure Gauge
  • Hydraulic units include agitation
  • 3 Electric Shutoff Valves (Hydraulic Package)

Coulter Injection Options

Enhance application accuracy with precision injection systems:

• 20” Rippled Coulter Blade
• Stainless Steel Straight Stream Nozzle
• Heavy-Duty Injector Bracket
• Check Valve Assembly
• Toolbar Plumbing Included

Available configurations:

• Knife Injection Kit
• V-Stream Nozzle Injection Kit

Yield Flexx & Gauge Wheel Options

• Yield Flexx Drop System – Improves application flexibility and placement
• Heavy Duty Gauge Wheel Kit – Enhanced durability in tough conditions
• Standard Gauge Wheel Kit (deduct option available)

Control & Technology Options

• Electric/Hydraulic Double Fold Switch
• Flowback Ball Valve Add-On
• Raven Control Systems:
  • Raven Component Kit
  • Raven ISO Kit (multiple configurations available)
  • 450 Controller Kit

Why Choose the ASLA9000 Series Liquid Applicator?

• High Capacity = Fewer Refills, More Acres Covered
• Precision Application = Better Input Efficiency
• Durable Construction = Built for Long-Term Performance
• Customizable Options = Built to Fit Your Operation

From fertilizer application to liquid nutrient management, the LA9000 Series gives you the control, capacity, and reliability needed to get the job done right—every time.

Applications

• Liquid Fertilizer Application
• Nutrient Management Programs
• Row Crop Farming
• Large Acreage Operations
